36Spring Brakes and Parts

SPRING BRAKE CHAMBERS, CONTINUED SERVICE CHAMBERS P/N Type Stroke PRLSC09HDA Type 9 1.75” K7 KSC12 Type 12 1.75” K7 KSC16 Type 16 2.25” K7 KSC20 Type 20 2.25” AK SC20 Type 20 2.25” PRLSC20LSHDA Type 20 XL 3.00” K7 KSC24 Type 24 2.25” PRLSC24HDA Type 24 LS 2.50” PRLSC24LSHDA Type 24 XL 3.00” K7 KSC30 Type 30 2.50” PRLSC30LSHDA Type 30 XL 3.00” PRLSC36HDA Type 36 3.00” PIGGY BACK KITS P/N Type Stroke PRLPS2024HDA Type 20/24 2.50" PRLPLBPS2424K Type 24/24 Kit 2.50" PRLPLBPS2424KLS* Type 24/24 LS Kit 2.50" PRLPLBPS2430K Type 24/30 Kit 2.50" PRLPLBPS2430KLS Type 24/30 LS Kit 3.00" PRLPS3036HDA Type 30/36 2.50" PRLPLBPS-3036KLS Type 30/36 LS Kit 3.00" PRLPLBPS3636 Type 36/36 3.00" COMPLETE ASSEMBLIES P/N Type Stroke PRL2024HDA Type 20/24 2.50" PRL2424HDA Type 24/24 2.50" PRL2424LSHDA* Type 24/24 LS 2.50" PRL2430HDA Type 24/30 2.50" PRL2430LSHDA* Type 24/30 LS 3.00" PRL3036HDA Type 30/36 2.50" PRLPLBTS3036LS Type 30/36 LS 3.00" PRL3636-2.5 Type 36/36 2.50" PRL3636HDA Type 36/36 3.00" HDA * “L” suffix chambers have the heavier return spring inside to accommodate the long stroke application AIR DISC BRAKE CHAMBERS P/N Type Application BW K028039 Chamber T14 Truck Universal BW K028226 Chamber T16 Truck Universal BW K028022 Chamber T18 Truck Universal BW K028225 Chamber T20 Truck Universal BW K028252 Chamber T24 Truck Universal BW K042457 Chamber 16/24 Universal BW K132352 Chamber 18/24 Universal BW K041960 Chamber 20/24 Universal PRLPL1624.D Economy Chamber 16/24 Universal PRLPL1824.D Economy Chamber 18/24 Universal PRLPL2024.D Economy Chamber 20/24 Universal WB 9253470060 Tristop 18/24 DDSB Disc Brake UNHANDED MAXX 22T: AAL, AAEDL, AAEDT, AANLS WB 9253470070 Tristop 18/24 DDSB Disc Brake LEFT HANDED MAXX 22T: AAT, AANT WB 9253470080 Tristop 18/24 DDSB Disc Brake RIGHT HANDED MAXX 22T: AAT, AANT WB 9253800200 Tristop 20/24 DDSB Disc Brake UNHANDED PAN22: AAL, AAEDL, AAEDT, AANLS WB 9253800210 Tristop 20/24 DDSB Disc Brake LEFT HANDED PAN22: AAT, AANT WB 9253800220 Tristop 20/24 DDSB Disc Brake RIGHT HANDED PAN22: AAT, AANT BW K132352 CLEVIS P/N Type PRL30CL1/2HDA Clevis Forged 1/2” Pin 1/2-20 PRL30CLHDA Clevis Forged 1/2” Pin 5/8-18 PRL30CL5/8HDA Clevis Forged 5/8” Pin 5/8-18 PRLPL1/2PIN Clevis Pin 1/2” PRL5/8PINHDA Clevis Pin 5/8” RI R810019 Std Stroke Straight 5/8" RI R810021 Long Stroke Straight 5/8" RI R810025 Std Stroke 5/8" Offset AUT179.YK5012 For Type 9,12,16 Straight RI R810024 For Type 9,12,16 5/8 Offset DIAPHRAGMS P/N Type Stroke AUT179.DT9 Type 9 1.75” AUT179.DT12 Type 12 1.75” AUT179.DT16 Type 16 2.25” AUT179.DT20 Type 20 2.25” AUT179.DT24 Type 24/L 2.25” AUT179.DT20L Type 20L 2.50” AUT179.DT30 Type 30 2.50" AUT179.DT24XL Type 24XL 3.00” AUT179.DT30 Type 30 2.50” PRLD303HDA Type 30L 3.00” AUT179.DT36 Type 36 3.00” https://youtu.be/XVmRCPSVQrM TECH Tips TRUCK SPRING CAGE BOLT SOCKET P/N MEDLIS-49000 Quickly Unlocks Truck Air Brakes • Extra deep 3/4" socket loosens the cage bolt to unlock air brakes on trucks • Also removes the air brake booster for replacement • Use with a 1/2" drive or 7/8" hex • Can be used with an impact wrench CAGING BRAKE CHAMBERS Garage Guru Ken Boyer walks you through the steps of caging brake chambers for heavy duty brake systems.
