CATALOG NUMBER 34 Ultimate Load Capacity 200,000 lbs Lift Capacity 62,500 lbs Side Load Capacity 32,000 lbs Turns Per Inch High Gear 2.5, Low Gear 33.8 Floating Nut Design No Warranty 5 Year Std. Performance Guarantee ADDITIONAL OPTIONS No Lube Low Profile Sandshoe Heavy Duty 12" x 17" Sandshoe Self-Leveling Foot Removable Cushion Foot 10 Yr Performance Guarantee, No Lube- Low Maintenance System Positioned as the best overall landing gear model, the Mark V is suitable for all standard and heavy duty applications. Unsurpassed features ensure that the Mark V delivers the absolute best in Holland landing gear. Ext Length Retracted Length # HH LGS-3A105 16.5" Travel Standard Sand Shoe Set w/ Hardware 48.6" 32.1" HH XA-S8-3A105 2 Speed - Gear Side HH XA-S9-3A105 Single Speed - Slave Side # HH LGS-3A024 16.5" Travel Cushion Foot Set w/ Hardware 47.1" 30.6" HH XA-S8-3A024 2 Speed - Gear Side HH XA-S9-3A024 Single Speed - Slave Side # HH LGS-3A001 16.5" Travel Self-Leveler Set w/ Hardware 47.3" 30.8" HH XA-S8-3A001 2 Speed - Gear Side HH XA-S9-3A001 Single Speed - Slave Side Ultimate Load Capacity 170,000 lbs Lift Capacity 55,000 lbs Side Load Capacity 30,000 lbs Turns Per Inch High Gear 4.5, Low Gear 35.7 Floating Nut Design Yes Warranty 5 Year Std. Performance Guarantee *Pictured with a Removable Cushion Foot ADDITIONAL OPTIONS Low Profile Sandshoe Heavy Duty Sandshoe Removable Cushion Foot 10 Yr Performance Guarantee No Lube- Low Maintenance System Positioned as an all around workhorse and is suitable for the majority of applications and represents the largest volume model produced. The ATLAS 55 features the patented constant mesh gear shifting technology and the exclusive floating nut with twin bulkhead design - engineered to ensure durable and easy operation for years to come. ATLAS 55 Ext Length Retracted Length # HH LG4001-700000078 17" Travel Standard Shoe Set w/ Hardware 48.2" 31.2" HH LG4001-710000000 Left Hand - Slave Side HH LG4001-720000000 Right Hand - Gear Side # HH LG4003-700000078 17" Travel Low Profile Shoe Set w/ Hardware 45.7" 28.7" HH LG4003-710000000 Left Hand - Slave Side HH LG4003-720000000 Right Hand - Gear Side # HH LG4001-900000078 19" Travel, Standard Shoe Set w/ Hardware 52.7" 33.7" HH LG4001-910000000 Left side - Slave side HH LG4001-920000000 Right side - Gear side MARK V LG Install Kit HH LG2790 • Value line, standard dry van use • 2 Speed, 3 Shaft Static Load Capacity 160,000 lbs Lift Capacity 50,000 lbs Side Load Capacity 29,000 lbs Turns Per Inch High Gear 4.5, Low Gear 34.4 Mounting 8 Universal Warranty 5 Year Warranty EVOLUTION ECONOMY STANDARD DUTY VG LG-REV-ST 17" Standard Shoe VG LGREV350-5-410SS-NG Left Hand - Non-Gear Side VG LGREV350-5-410SS-GS Right Hand - Gear Side VG LG-REV-LP 17" Low Profile Sand Shoe VG LGREV350-5-210SS-NG Left Hand - Non-Gear Side VG LGREV350-5-210SS-GS Right Hand - Gear Side HARDWARE KITS Install Kit HH RK-V-06388 Kit Includes: • 1 - 3/8" -16 x 2-1/4" Bolt • 2 - 3/8" - 16 x 2" Bolts • 2 - 3/8" Washers • 3 - 3/8" Lock Nuts • 1 - Crank Handle Holder Accessory Kit HH 785KIT Kit Includes: • 1 - 6.75" Crank Handle • 2 - Strut Brackets • 1 - Pre-Cut 64.5" Cross Shaft • 1 - Crank Handle Holder with hardware Hardware NOT included • Powdercoated • 17" Travel Maintenance Free TRAILER BODY PARTSLanding

Standard Shoe Low Shoe AUT568.1001 17" Travel Standard Shoe Static Load 176,000 lbs Lift Capacity 60,000 lbs 10 hole wide mounting flange Standard Wt. 206 lbs AUT568.1012 19" Travel Standard Shoe AUT568.1017 17" Travel Low Shoe Static Load 160,000 lbs Lift Capacity 50,000 lbs 8 hole mounting flange Standard Wt. 187 lbs LANDING GEAR KITS • Universal Mounting on Either Side of Frame • Includes hardware • Forged steel gearing • Meets or exceeds TTMA / AAR requirements High Gear 3.3 turn / inch of travel Low Gear 25.4 turn / inch of travel DRY VANS/REEFERS Outside Mount, 10" x 10" Cushion Foot, 17" Travel STOA400-G-17 Landing Gear Set w/ hardware STOA400-G-17-LEGS Landing Gear Set - Legs Only STOA400L-G-17 Non-Gear Side Leg STOA400R-G-17 Gear Side Leg Inside Mount, 10" x 10" Cushion Foot, 17" Travel STOA401-G-17 Landing Gear Set w/ hardware STOA401-G-17-LEGS Landing Gear Set - Legs Only STOA401L-G-17 Non-Gear Side Leg STOA401R-G-17 Gear Side Leg Inside Mount, 10" x 10" Low Profile Cushion Foot, 17" Travel STOA401-G3-17 Landing Gear Set w/ hardware STOA401-G3-17-LEGS Landing Gear Set - Legs Only STOA401L-G3-17 Non-Gear Side Leg STOA401R-G3-17 Gear Side Leg Inside Mount, 10" x 10" Standard Sand Shoe, 17" Travel STOA401-T-17 Landing Gear Set w/ hardware STOA401-T-17-LEGS Landing Gear Set - Legs Only STOA401L-T-17 Non-Gear Side Leg STOA401R-T-17 Gear Side Leg TANK/FLATBEDS Outside Mount, 10" x 10" Standard Sand Shoe, 19" Travel STOA400-T-19 Landing Gear Set w/ hardware STOA400-T-19-LEGS Landing Gear Set - Legs Only STOA400L-T-19 Non-Gear Side Leg STOA400R-T-19 Gear Side Leg AUT568.1023+ Internal Gear Landing Gear Set w/ Hardware Outside Mount, 10" x 10" Standard Sand Shoe, 17" Travel STOA400-T-17 Landing Gear Set w/ hardware STOA400-T-17-LEGS Landing Gear Set - Legs Only STOA400L-T-17 Non-Gear Side Leg STOA400R-T-17 Gear Side Leg AUT568.1014+ Internal Gear Landing Gear Set w/ Hardware A400 SERIES LANDING GEAR CAPACITIES & RATINGS Max. Static Load Rating*: 160,000 lbs Rated Lift Capacity**: 55,000 lbs Side Load Capacity*: 29,000 lbs per set *When properly braced on a trailer. **With 100ft-lbs input torque. GEAR RATIO High Gear: 3.5 Turns = 1” Travel Low Gear: 32 Turns = 1" Travel FEATURES » BENEFITS No External Gearbox » Gears Protected and No Shaft Misalignment All Austempered Ductile Iron Gears » Gears Will Not Wear Out Spline Shifting » Easy Shifting Double “D” Crank » Transfers Crank Torque Directly Into Shaft OUTSIDE MOUNT HARDWARE STOB10066.68.4 O/M Cross Shaft AUT568.1021 Crank Handle STOB10261 Crank Holder HH XA-V-1938 Brace Lugs MISC. HARDWARE STOC10717 Cushion Foot Repair Kit AUT568.1028 Cushion Foot Pad LOPRO STOUGHTON CRANK HANDLES STOC10592.2 Vertical Crank Handle STOC10591.2 Horizontal Crank Handle LANDING GEAR HARDWARE INSIDE MOUNT HARDWARE STOB10363.56.5 I/M Cross Shaft AUT50644000 Crank Handle STOB10261 Crank Holder HH XA-V-1938 Brace Lugs +Not Jost

Throw 14" Length P/N Width Length Hole Center FE 013-01192 10" 10" 4.44" FE 013-01196 12" 12" 4.44" HH 50616001 11.81" 10" 4.50" UNIVERSAL VERTICAL FOLDING CRANKS STANDARD DESIGN SAND SHOES SAND SHOES LOW MOUNT SAND SHOES P/N Length FE 013-00437 11.5" HH 50644017 11.63" AUT568.1005 15.5" P/N Length AUT568.1021 6.75" FE 013-00437 11.5" MARK V VERTICAL FOLDING CRANKS VERTICAL FOLDING CRANKS Sold Each Sold Each Throw 14" Length P/N Weight (lbs.) Width Length Hole Center HH 50616008 9.00 10" 10" 1.94" FE 013-01604 10.50 12" 12" 1.94" L300 SERIES- AMERICAN EAGLE LANDING GEAR Cost Effective & American Made The L300 landing gear continues to have the internal gear train and features of the standard JOST landing gear models. CAPACITIES & RATINGS Max. Static Load Rating*: 140,000 lbs Rated Lift Capacity**: 50,000 lbs Side Load Capacity*: 26,000 lbs per set *When properly braced on a trailer. **With 100ft-lbs input torque. GEAR RATIO High Gear: 3.5 Turns = 1” Travel Low Gear: 32 Turns = 1" Travel Outside Mount, 10" x 10" x 4.5" Standard Shoe, 17" Travel JSTL300.T.17 Landing Gear Set w/ hardware JSTL300.T.17-LEGS Landing Gear Set - Legs Only JSTL300L.T.17 Non-Gear Side Leg JSTL300R.T.17 Gear Side Leg Inside Mount, 10" x 10" x 2.8" Low Profile Cushion Foot, 17" Travel JSTL301.G3.17 Landing Gear Set w/ hardware JSTL301.G3.17-LEGS Landing Gear Set - Legs Only JSTL301L.G3.17 Non-Gear Side Leg JSTL301R.G3.17 Gear Side Leg Inside Mount, 10" x 10" x 5.7" Standard Cushion Foot, 17" Travel JSTL301.G.17 Landing Gear Set w/ hardware JSTL301.G.17-LEGS Landing Gear Set - Legs Only JSTL301L.G.17 Non-Gear Side Leg JSTL301R.G.17 Gear Side Leg Inside Mount, 10" x 10" x 4.5" Standard Shoe, 17" Travel JSTL301.T.17 Landing Gear Set w/ hardware JSTL301.T.17-LEGS Landing Gear Set - Legs Only JSTL301L.T.17 Non-Gear Side Leg JSTL301R.T.17 Gear Side Leg • Welded Steel Construction, Black Primer Finish • Axle Kits Include Hardware Kit Consisting of: Hex Bolt, Lock Nut, Half Collar P/N Width Length Thickness Application HH 50616043 8.50" 1.88" Std. Foot WELDED CAP AXLE & HARDWARE KITS 51000 Series/Atlas 55 HH RK-11289 Mark V HH RK-11287 GEAR BOX REBUILD KITS K-BRACE Part Number NL WAB13001048-01G Roadside VG TM700-4-451 VG TM700-4-452

MIDWESTWHEEL.COM MEMBER KANSAS CITY 5801 E. Front St. Main ....(816) 471-1552 Parts....(800) 821-7402 JOPLIN 2424 Stephens Blvd. Main ....(417) 717-6022 Parts....(866) 318-9111 SPRINGFIELD 812 Lillian Dr. ∙ Strafford, MO Main ....(417) 429-2476 Parts....(800) 785-3705 SIOUX CITY 1819 4th St. Main ....(712) 252-7969 Parts....(800) 943-3534 CEDAR RAPIDS 200 50th Ave. S.W. Main ....(319) 365-4453 Parts....(800) 332-5435 DES MOINES 1436 E. Ovid Ave. Main ....(515) 265-1491 Parts....(800) 888-0248 CLEAR LAKE 840 Hwy. 18 W. Main ....(641) 357-7101 Parts....(800) 397-5630 DAVENPORT 8502 Northwest Blvd. Main ....(563) 322-2671 Parts....(800) 553-1886 OMAHA 9770 S 142nd Street, Suite 1 Main ....(531) 239-3050 Parts....(800) 322-8757 NEBRASKA IOWA MISSOURI December 12, 2025 (34Trailer Landing Gear) [50.8mm] 2.00" [42.2mm] 1.66" [16.8mm] Ø .66" + (2 PLACES) [109.5mm] 4.31" [109.5mm] 4.31" [78.5mm] 3.09" [78.5mm] 3.09" P/N Hole Center Adjustment HH 50618012 26"-41" HH 50618013 42"-57" HH 50618014 58"-72" Crank Hanger STOB10261 MISC. HARDWARE CROSS DRIVE SHAFT Brace Ear HH LG0266 P/N Length HH 50618005 Adjustable Shaft 53" - 71" HH LG0094-6450 64.5" Pre-cut HH LG0094 68" 2 PIECE ADJUST-A-BRACE KITS & COMPONENTS Heavy-Duty Kit • High strength steel tubing with reinforced end sections for greater tear-out resistance • Black E-Coat Finish • 0.66" Diameter Mounting Holes • Kits include: one side loaded end & one side loaded insert with 15.00" Adjustment MOUNTING BRACKET WING PLATES LANDING GEAR BRACKETS Part Number NL UTL03-1103-0-077 Roadside NL UTL03-1103-0-078 Curbside VG TM700-4-451 - VG TM700-4-452 - VG TM700-4-450 - Part Number NL UTL03-1103-0-123 Roadside NL UTL03-1103-0-124 Curbside NL 4-A1-224L Roadside NL 4-A1-224R Curbside VG TM700-4-450 NL UTL03-1103-0-077 NL UTL03-1103-0-078 Multi-purpose adhesive sealant with a wide adhesion range Sikaflex®-221 is a multi-purpose 1-component polyurethane adhesive / sealant that bonds well to a wide variety of substrates like metals, metal primers and paint coatings (2-component systems), ceramic materials and plastics. It is suitable for making permanent elastic seals. • Bonds well to a wide variety of substrates • Resistant to ageing • Can be sanded and painted • Passes EN45545-2 R1/R7 HL3 • Non-corrosive • Low odor General purpose, one-component, non-sag, elastomeric, RTV acetoxy silicone sealant with good adhesion characteristics for general sealing and bonding applications. Maintains elastomeric properties up to 350° F continuous, 392°F intermittent. • One-component ready to use • Excellent adhesion, bonds to many substrates without priming • Contains anti-microbial additive for mold resistance • Fast Cure - Move assembled or sealed parts quickly VG SIK221-242 Gray 10.3 oz. Cartridge VG SIK221-241 White 10.3 oz. Cartridge VG SIK221-253 Black 10.3 oz. Cartridge VG SIK432063 Clear 10 fl. oz. (295ml) ACCESSORIES SIKAFLEX®-221 SIKASIL® GP
