22AC Products and Equipment

Compressors.........................................................2-5 Clutches................................................................... 5 Receiver Driers......................................................6-7 Blower Motors & Wheels.......................................8-9 Expansion Valves......................................................9 Heater Vales & Actuators........................................10 Switches & Relays.............................................10-11 Resistors, Interior Dash Switches...........................12 Condensers.......................................................13-14 Evaporators.......................................................14-15 Heater Cores..........................................................15 Antifreeze............................................................... 15 A/C Hose & Fittings...........................................16-17 Expansion Tubes, Service Caps...............................17 O-Ring/Seals & O-Ring Assortment Kits.............18-19 Cabin Air Filters......................................................20 Leak Detectors.......................................................20 Thermometers. ...................................................... 21 Injectors & Kits, Fluorescent Dyes...........................21 Maintenance Parts, Systems & Components......21-23 Schrader Valves & Tools.........................................22 Refrigerant............................................................. 23 Retrofit Fittings, Oil, Manifold Gauge Kits................24 A/C PRODUCTS & EQUIPMENT OFFERING A GOOD, BETTER, BEST GRADE OF COMPRESSORS CATALOG NUMBER 22

2 COMPRESSORS - SANDEN STYLE *Uses SP15 PAG Oil **Uses R12 Mineral Oil Model Mount Clutch Volt Sanden # ME 5285 FLX7 Universal Style Direct 10gr 12 ME 5771* 300cc R134a 7H15 Ear 2gr 132mm 12 4603/4469 ME 5331* 300cc R134a 7H15 Direct 8gr 119mm 12 4776/4482/4421 ME 5363 300cc R134a 7H15D Ear 2gr 125mm 12 4740/4713/4484 ME 5362* Generic #5362Q 300cc R134a 7H15E Direct 6gr 125mm 12 4731/4424 ME 5366 Generic #5366Q 300cc R134a 7H15E Direct 6gr 125mm 12 4792/4040 ME 5348* 200cc R134a 7H15E Direct 8gr 119mm 12 4816/4544 ME 5365* Generic #5365Q 300cc R134a 7H15E Direct 8gr 119mm 12 4759/4042 ME 5400 300cc R134a 7H15E Direct 10gr 119mm 12 4347 ME 54720 300cc R134a 7H15E Direct 8gr 119mm 12 4720 ME 5373 300cc R134a 7H15HD Ear 2gr 125mm 12 4426/4696 ME 5727* 300cc R134a 7H15HD Ear 2gr 125mm 12 4627/4896 ME 5290 200cc R134a 7H15HD Ear 2gr 132mm 12 4434 ME 5382* 300cc R134a 7H15HD Direct 2gr 132mm 12 4715/4778/4890 ME 5384 300cc R134a 7H15HD Ear 2gr 132mm 12 4717/4777/4893 ME 5726* 300cc R134a 7H15HD Direct 2gr 132mm 12 4626/4780 ME 5764* 240cc R134a 7H15HD Ear 2gr 132mm 12 4644/4664/8104 ME 5334* 300cc R134a 7H15HD Direct 6gr 125mm 12 4819/4473 ME 5339 300cc R134a 7H15HD Direct 6gr 125mm 12 4883/4092 ME 5347* 200cc R134a 7H15HD Direct 6gr 125mm 12 4815/4793 ME 5387 300cc R134a 7H15HD Direct 6gr 125mm 12 4494/4757 ME 54546 300cc R134a 7H15HD Direct 6gr 125mm 12 4546 ME 5706 135cc R134a 7H15HD Ear 7gr 119mm 12 4618 ME 5323 300cc R134a 7H15HD Ear 8gr 119mm 12 4305/4496/4718 ME 5326* 300cc R134a 7H15HD Ear 8gr 119mm 12 4734/4477 ME 5333* 300cc R134a 7H15HD Direct 8gr 119mm 12 4818/4485 ME 5393 300cc R134a 7H15HD Direct 8gr 119mm 12 4418 ME 5707 240cc R134a 7H15HD Direct 8gr 119mm 12 4666 ME 5385* Generic #5385G 300cc R134a 7H15HD Direct 8gr 130mm 12 4493/4733/4892 ME 5402 240cc R134a 7H15SHD Direct 12gr 126mm 12 4078/4370 ME 5300 285cc R134a 7H15SHD Ear 2gr 152mm 12 4609/4478 ME 5395 300cc R134a SHDC Direct 8gr 119mm 12 4314 ME 5398 300cc R134a SHDC Direct 8gr 140mm 12 4802 ME 5406 300cc R134a SPRHD Direct 8gr 119mm 12 4398 ME 5404 300cc R134a SSPRHD Direct 8gr 180mm 12 4326 ME 54577 300cc R134a SD7H15-Super HD Direct 7gr 126mm 12 - ME 5316 300cc R134a SD7H15-SHD Direct Long 8gr 132mm 24 4769 ME 54148 300cc R134a SD7H15-Super HD 8gr 130mm 12 4006;4146 ME 54106 300cc R134a SD7H15-Super HD 6gr 125mm 12 - ME 5349 300cc R134a SD7H15HD Direct Long 8gr 119mm 12 - ME 54667 300cc R134a 7H15HD Direct 8gr 119mm 12 4667 ME 54732 300cc R134a SD7H15-Super HD 8 gr 180mm 12 4732 ME 54585QS (Que Mfg. Sup HD (N .E.) 300cc R134a 7H15E Direct 6gr 119mm 12 4585 ME 59039QS 300cc R134a QP7H15-Super HD 6 gr 125mm 12 Sanden Style ME 59934QS 300cc R134a QP7H15-Super HD 8 gr 119mm 12 Sanden Style

3 COMPRESSORS - SANDEN STYLE, CONTINUED COMPRESSORS - SELTEC / VALEO STYLE ***Uses SP10 PAG Oil ME 5333 ME 5334 ME 5348 ME 5362 ME 5347 ME 5339 ME 5363 ME 5366 ME 5400 ME 5373 ME 5365 ME 54720 ME 5382 ME 5385 ME 5393 ME 5384 ME 5387 ME 5395 ME 5726 ME 5727 ME 5764 ME 5771 ME 5707 ME 5805 ME 5800 ME 5903 ME 5326 ME 5331 ME 5300 ME 5285 ME 5323 ME 5398 ME 5402 ME 54546 ME 5406 ME 5706 ME 5404 ME 5806 Model Mount Clutch Volt Head OE # ME 5800 R134a TM16 Ear 8gr 5" 12 B xxx-46121 ME 5805 Valeo R134a TM16 Ear 8gr 4.8" 12 G xxx-46234 ME 5806 Universal R134a TM16 Ear 8gr 5" 24 G xxx-46236 ME 54577 ME 54585QS ME 54667 COMPRESSORS - DENSO ME 5405 (O.E.M.) ME 5405G (Aftrmrkt) 8 Grv., 163.5mm Dia. OE# 22-65771-000 ME 5405A (O.E.M.) ME 5405AG (Aftrmrkt) 8 Grv., 140mm Dia. OE# 22-65770-000 ME 51416 6 Grv., 163.5mm Dia. OE# 22-65772-000

4 In most applications, New Super Heavy Duty Compressors will replace the standard models. Check clutch clearance before installing on vehicle. COMPRESSORS - T/CCI (YORK STYLE) ME 5266 2 Wire Model Clutch ET 210L 2gr 6" Volt Head T/CCI # 12 Tube-O 25237C CCI York New 209/210 Uses PAG Oil ME 5236 Model Clutch ER 210L None Volt Head T/CCI # N/A RotaLock 25149 CCI York New 209/210 Uses PAG Oil ME 5256 Generic #5216 Model Clutch ET 210L None Volt Head T/CCI # N/A Tube-O 25150 CCI York New 209/210 Uses PAG Oil ME 5262 Generic #5217 1 Wire Model Clutch ET 210L 2gr 6" Volt Head T/CCI # 12 Tube-O 25073C CCI York New 210L Uses PAG Oil Uses PAG Oil ME 5264 1 Wire Model Clutch ET 210L 6gr 5-7/8" Volt Head T/CCI # 12 Tube-O 25182C COMPRESSORS - SUPER HEAVY DUTY 300cc R134a Model Mount Clutch SPRHD Direct 6gr 125mm Volt Head Sanden # 12 GSA 4376 ME 5362S 300cc R134a Model Mount Clutch SPRHD Direct 8gr 119mm Volt Head Sanden # 12 GH 4075/4352 ME 5333S 300cc R134a Model Mount Clutch 7H15SHD Direct 8gr 130mm Volt Head Sanden # 12 WV 4286 ME 5385S 300cc R134a Model Mount Clutch SPRHD Direct 8gr 119mm Volt Head Sanden # 12 GQ 4077/4368 ME 5365S 300cc R134a Model Mount Clutch SPRHD Direct 6gr 125mm Volt Head Sanden # 12 GQ 4080/4377 ME 5366S • New Heavy Duty Design for greater durability and longer service life, twice as long as Standard Models • Original Equipment on later model, class 8 vehicles: Freightliner, Peterbilt, Volvo, and Mack • Doubles the number of life clutch cycles (1 million) • Increased friction surface diameter on clutch rotor • Same wobble plate design and performance as current SD7 compressors • Larger Face with a friction lined clutch rotor for better engagement • Rubber clutch armature replaces and eliminates leaf spring armature Thermal Fuse SUPER HEAVY DUTY COMPRESSOR (SHDC) THERMAL FUSE DESIGN Thermal Fuse in Clutch Coil • Placed inside the clutch coil to sensor high heat temperature • Function: As the fuse senses extreme heat from clutch slippage, the thermal fuse breaks open. With the open fuse, it will not allow the electrical current to flow to the clutch coil. This function disengages the clutch armature from the clutch pulley and allows the clutch pulley to spin freely acting as an idler pulley. • The thermal fuse prevents the loss of the accessory drive belt • The thermal fuse can’t be reset or replaced after breaking open. The compressor must be replaced and normal maintenance to the system must be performed. • Position of thermal fuse is located in the clutch coil • New Heavy Duty Extra Pure (EP) steel bearing in clutch rotor • Increased internal oil flow passages to increase oil flow to lip seal • Improved over-molded lip seal, increases the ability to seal when shaft “waggles” during compressor operation • Improved rear thrust bearing race • Improved rod swage joint quality with special alumite coating • Thermal fuse added to coil for disengagement of clutch pulley • Prevents clutch from locking up and throwing accessory drive belt

5 COMPRESSORS - T/CCI (YORK STYLE), CONTINUED ME 5269 2 Wire Model Clutch ET 210L 8gr 6 1/8" Volt Head T/CCI # N/A Tube-O 25246C ME 5267 2 Wire Model Clutch ET 210L 6gr 5 7/8" Volt Head T/CCI # 12 Tube-O 25240C ME 5271 2 Wire Model Clutch ES 210L 8gr 6 1/8" Volt Head T/CCI # 12 SlimLine 25238C Uses PAG Oil Uses PAG Oil Uses PAG Oil ME 5268 2 Wire Model Clutch ET 210L (Far Forward) 6gr 5-7/8" Volt Head T/CCI # 12 Tube-O 25243C CCI York New 209/210 Uses PAG Oil CLUTCHES - T/CCI (YORK STYLE) ME 5125 Blissfield/CCI OE#: 14533 Volt: 12V Dia.: 6" Grooves: 1 Width: 1/2" A-B Dist.: 2 3/4" 2 Wire Plug Metripak ME 5126 Blissfield/CCI OE#: 14432 Volt: 12V Dia.: 6" Grooves: Poly 6 Width: .14" A-B Dist.: 2-3/8" center 2 Wire Plug w/Diode ME 5129 Blissfield/CCI OE#: 14565 Volt: 12V Dia.: 6" Grooves: Poly 6 Width: .14" A-B Dist.: 2-1/8" center 2 Wire Plug w/Diode ME 5128 Blissfield/CCI OE#: 14372 Volt: 12V Dia.: 6-5/16" Grooves: Poly 8 Width: .14" A-B Dist.: 1-5/8" center 2 Wire Plug Metripak ME 5144 York-Tecumseh OE#: 501939, 024-21590 Volt: 12V Dia.: 6" Grooves: 2 Width: 1/2" A-B Dist.: 1-11/16" / 2-5/16" 1 Wire Plug, Weatherpak ME 5044 York-Tecumseh OE#: 332639, MAE-6AR, MA-6A Volt: 12V Dia.: 6" Grooves: 2 Width: 1/2" A-B Dist.: 1-11/16" / 2-5/16" 1 Wire ME 5063 OE#: 502400 Volt: 12V Dia.: 7-5/16" Grooves: 1 Width: 3/4" A-B Dist.: 2" 1 Wire Plug ME 5131 Blissfield/CCI OE#: 508888, MAM-13 Volt: 12V Dia.: 6" Grooves: 1 Width: 1/2" A-B Dist.: 2-3/4" center 1 Wire IHC Plug ME 5145 Blissfield/CCI OE#: 024-25238 Volt: 12V Dia.: 6" Grooves: 2 Width: 1/2" A-B Dist.: 1-11/16" / 2-5/16" 2 Wire Plug Metripak ME 5030 York-Tecumseh OE#: 513352, MAN-03 Volt: 12V Dia.: 5.8" Grooves: Poly 6 Width: .14" A-B Dist.: 2-1/8" center 1 Wire, IHC Plug ME 5031 York-Tecumseh OE#: 502409 Volt: 12V Dia.: 6" Grooves: 1 Width: 1/2" A-B Dist.: 2-3/4" 1 Wire Plug, Weatherpak ME 5032 York-Tecumseh OE#: 503879, 515528, MAN-06 Volt: 12V Dia.: 6-5/16" Grooves: 1 Width: 5/8" A-B Dist.: 2-3/4" 1 Wire, IHC Plug ME 8990 30 ft. Roll A/C INSULATION TAPE ME 5063 OE#: 502400 Volt: 12V Dia.: 7 5/16" Grooves: 1 Width: 3/4" A-B Dist.: 2" 1 Wire Plug CLUTCHES - SANDEN STYLE

6 RECEIVER DRIERS P/N Dia. Length In/Out ME 7118 2-1/2" 8" 3/8" x 3/8" Male O-Ring Top Sight Glass, Female Switch Port, 1/4" Male Switch Port ME 7480 2-1/2" 8-1/4" 3/8" x 3/8" Male O-Ring Top Sight Glass, Switch Port ME 7156 2-3/4" 10" 3/8" x 3/8" Male O-ring Top Sight Glass, Side Switch Port, Pressure Relief Valve ME 7417 2-3/4" Pad Mount Accumulator Navistar Prostar 3670134-C1, P6546001 ME 7126 3" 6-1/2" 3/8" x 3/8" Male O-ring Top Sight Glass, Side 1/4" Schrader Valve, High Pressure Relief Valve ME 7123 3" 6-1/2" In/Out - 3/8" Male O’Ring Red Dot Unit Applications RD-5-7272-0 ME 7135 3" 8" In: 3/8" Male O-Ring Out: 3/8" Female O-Ring Top Sight Glass, (2) Schrader Valves, Moisture Indicator, Pressure Relief Valve ME 7160 3" 8" 3/8" x 3/8" Male O-Ring Top Sight Glass, (2) Schrader Valves, Fuse Plug ME 7161 3" 8" 3/8" x 3/8" Male O-Ring Top Sight Glass, (2) Schrader Valves, Fuse Plug ME 7169 3" 8" In: 3/8" Male O-Ring Out: 3/8" Female O-Ring Top Sight Glass, (2) Schrader Valves, Pressure Relief Valve ME 7143 3" 8-1/4" 3/8" x 3/8" Male O-Ring Top Sight Glass, Schrader Valve, Fuse Plug, Moisture Indicator ME 7141 3" 8-1/4" 3/8" x 3/8" Male O-Ring Side Sight Glass, Top Switch Port ME 7159 3" 9" 3/8" x 3/8" Male O-Ring Top Sight Glass, Top Schrader Valve, Moisture Indicator, Pressure Relief Valve ME 7419 3" 9" Inlet & Outlet: Male Insert O’Ring 3/8’’ #6 DRIER/2010-11 MACK 221RD44M; OEM Number: 221RD44M ME 7635 3" 9" Inlet: Pad Type; Outlet: Pad Type Receiver Drier Mack/Volvo Trucks; OEM Number: 82771584 ME 7132 3" 10" 3/8" x 3/8" Male O-Ring Top Sight Glass, Top Schrader Valve, Moisture Indicator, Pressure Relief Valve ME 7134 3" 10" 3/8" x 3/8" Male O-Ring Top Sight Glass, Top Switch Port, Moisture Indicator, Pressure Relief Valve ME 7165 3" 10" 3/8" x 3/8" Male O-Ring Top Sight Glass, Schrader Valve, Pressure Relief Valve ME 7166 3" 10" 3/8" x 3/8" Male O-Ring Top Sight Glass, Pressure Relief Valve, Moisture Indicator, Metric Schrader Valve - M10 ME 7193 3" 10" 3/8" x 3/8" Male O-Ring Top Sight Glass, Fuse Plug, (1) 1/4" Port ME 7197 3" 10" 3/8" Slimline (2) M10 Switch Ports, Pressure Relief Plug, ABPN83-319744 ME 7230 3" 10" In: 11/16" Female O-Ring Out: 3/8" Female O-Ring Top Sight Glass, Pressure Relief Valve, 16mm Service Port; R-134a Only ME 7386 3" 10" Quick Disconnect Side Sight Glass, Moisture Indicator; R134a Only ME 7387 3" 10" 3/8" Male O-Ring Moisture Indicator, Side Sight Glass, Kenworth K251-566 ME 7412 3" 10-5/8" Inlet: Pad; Outlet: Pad Receiver Drier-Paccar; OEM Number: F37-1017-100 ME 7413 3" 10-5/8" Inlet: Pad Type #8; Outlet: Pad Type #8 Receiver Drier-Paccar; OEM Number: F37-1017-200 ME 7424 3" 10-5/8" In/Out - Pad Fittings Kenworth F37-1021 (steel), F37-1023 ME 7425 3" 10.5" Inlet/ Outlet: Pad-sealing washer type; Kenworth-Peterbilt F37-6016, 1000479477 ME 7393 3" 11" Manifold connection type R134a Only, Kenworth T2000, F37-6000 ME 7398 3" 11" Pad Manifold Fittings 365 thru 389 Series Peterbilt F37-6003 ME 7399 3" 11" Pad Manifold Fittings Peterbilt F37-6009 ME 7411 3" 11" Inlet: Pad Type #8; Outlet: Pad Type #8 Kenworth-Peterbilt Trucks; Receiver Drier, OEM Number: F37-1019 ME 7414 3" 11" Inlet: Pad Type #8; Outlet: Pad Type #8 Receiver Drier-Kenworth; OEM Number: F37-6017 ME 7397 3" 11" Inlet: 3/8", Paccar Pad; Outlet: Paccar Pad Kenworth F37-6002 ME 7415 3-7/16" 9-1/2" Pad Mount Accumulator (1) M12 Port, Navistar 3542577C2; BOA80-323-00-138 ME 7493F 3-1/2" 8-1/8" In: 5/8" #10 MIO Out: 5/8" #12 MIO O.E. Style Ford Accumulator (Steel) ME 7493G 3-1/2" 8-1/8" In: 5/8" #10 MIO Out: 5/8" #12 MIO Aftermarket Style Ford Accumulator (Aluminum) ME 7408 Accumulator 3-1/2" 9-1/8" Uses (2) #0017 O-Rings & #4589SR Fitting Peterbilt Pad 18-04171 ME 7409 3-1/2" 9-1/8" In: 1-1/16" Female O-Ring Out: 1-1/16" Male O-Ring Peterbilt 18-03837 ME 7559 4" 7" #8 Stat Seals Freightliner Columbia, M2 A22-63992-000, A22-63992-001 ME 7585 4" 7" Pad Mount Drier Freightliner Cascadia OE# 22-66700-000 ME 7586 4" 7" Pad Mount Drier Freightliner OE# A22-66600-000 ME 7233 4" 7-1/2" In - 3/8" Female O’Ring, Out - 3/8" Male O’Ring John Deere 0268464-5; AR59780; AR74486 ME 7421 Inlet: Pad Fitting; Outlet: Navistar Pad DRIER/NAVISTAR; with 2 pad manifold, OEM Number: 3839360-C92 ME 7422 Inlet: Pad Fitting; Outlet: Navistar Pad DRIER/NAVISTAR w/REAR AC; with 3pad manifold, OEM: 3843558-C92

7 RECEIVER DRIERS, CONTINUED ME 7166 Mack ME 7387 ME 7197 ME 7230 ME 7193 Western Star ME 7386 ME 7415 ME 7408 ME 7409 ME 7493G ME 7493F ME 7118 ME 7126 ME 7123 ME 7156 ME 7417 ME 7480 ME 7160 Freightliner ME 7161 Peterbilt ME 7169 Freightliner ME 7143 ME 7135 Freightliner ME 7141 ME 7165 Mack ME 7159 ME 7132 ME 7134 ME 7635 ME 7419 ME 7559 ME 7585 ME 7421 ME 7422 ME 7586 ME 7233 ME 7398 ME 7399 ME 7411 ME 7414 ME 7397 ME 7393 ME 7412 ME 7413 ME 7424 ME 7425

8 12V BLOWER MOTORS & WHEELS ME 3034 ME 3044 ME 3927 P/N Volt Rotation Shaft Length Overall Length Motor Length Motor Dia. Stud Span Spd. Vent Mount Type ME 3034 12 CW 1.65 4.75 4.00 3.00 - 1 Vented Strap ME 3927 12 REV 1.76 4.15 3.78 2.93 2.31 1 Vented Stud ME 3044 12 CW 2.09 4.59 3.84 3.00 2.31 1 Vented Stud P/N Volt Rotation Shaft Length Overall Length Motor Length Motor Dia. Stud Span Spd. Vent Mount Type ME 3182 12 REV 2.62 4.75 3.88 3.00 - 1 Vented Strap ME 3956 12 CW 1.46 4.46 4.60 2.92 - 1 Vented Stud 5/16" DIAMETER SINGLE SHAFT - 12 VOLT ME 3182 5/16" DIAMETER DOUBLE SHAFT STUD / STRAP MOUNT TYPE BLOWER HOUSING ASSEMBLIES P/N Volt Rotation Shaft Length Overall Length Motor Length Motor Diameter Stud Span Spd. Vent Mount Type Notes ME 3251 12 CCW 1.98 4.74 4.00 3.00 2.31 1 Vented Assm w/ wheels (2) Volvo 3946686; 2809-841-021 ME 3267 12 CW 1.63 4.50 3.69 3.25 - 1 Vented Flange Ford ME 3762 12 - - - - 3.00 - 1 Vented Flange w/ wheel Mack Vision. 2 wires ME 3917 12 - - - - - - - - - w/wheel, Paccar CR705001 ME 3924 12 CW 1.50 4.75 4.41 3.00 2.50 1 Vented w/ wheel Freightliner ME 3941 12 CW - - - - - 1 - Flange w/ wheel Navistar 3674285-C1 ME 3942 12 CW 1.06 4.75 4.25 3.13 .81 1 Vented Flange Threaded Shaft ME 3945 12 CW 1.62 5.00 4.69 3.00 2.50 1 Vented Flange Kenworth 203139BSM ME 3946 12 CW 1.66 5.14 4.69 3.00 N/A 1 Vented Flange Kenworth ME 3955 12 CCW - 4.25 - 3.30 - 1 Non Vent Flange Mack 3543-H9631, 85128713 ME 3965 12 CCW 1.18 4.09 4.09 3.00 N/A 1 Vented Flange Navistar 9000 Series ME 3967 12 CW - - - - - 1 - Flange w /wheel Freightliner/Volvo ME 3968 12 CW - - - - - 1 - Flange Navistar BOA80-415-00-879 ME 3972 12 CW - - - - - - - Flange Perterbilt ME 3973A 12 - - - - - - Variable Vented Flange Frieghtliner VCC35000003 (brushless) 5/16" DIAMETER DOUBLE SHAFT - 12 VOLT - FLANGE / PLATE MOUNT TYPE (WITH AND WITHOUT WHEELS) ME 3251 ME 3267 ME 3942 ME 3946 ME 3955 ME 3924 ME 3945 ME 3965 ME 3967 ME 3972 ME 3762 ME 3968 ME 3915 12V Prostar 2602570-C92 ME 3941 ME 3917 ME 3956 ME 3916 12V, 2 Wires, 4-3/8" x 12-1/4" VHD, VN, VT Series w/Behr - Main Unit OE# 85120276

9 12V BLOWER MOTORS & WHEELS, CONTINUED P/N Inlet Wheel Dia. Width Rotation Hub Inset Material ME 3650 Single 5-3/16" 3-3/8" CW 7/8" Steel ME 3673 Single 5-3/4" 3-1/4" CW - Plastic ME 3775 Single 5-3/4" 3-1/4" CW 5/16" Steel ME 3741 Single 6" 3" CCW 1-1/2" Plastic 5/16" DIAMETER BORE - SINGLE INLET P/N Inlet Wheel Dia. Width Rotation Hub Inset Material ME 3774 Double 5-1/2" 3-1/2" CW 2-1/4" Plastic ME 3772 Double 4-1/2" 3-3/8" DUAL 1-11/16" Plastic 5/16" DIAMETER BORE - DOUBLE INLET ME 3772 ME 3774 ME 3650 ME 3741 ME 3775 ME 3673 ME 1606 1-1/2 Ton Rating w/ Single Mounting Hole ME 1609 1-1/2 Ton Rating w/ 1 Switch Port, Nick Type, Navistar #1696846C3 ME 1602 2 Ton Rating ME 1621 1 Ton Rating 03-Up Freightliner Century Class ME 1688 2 Ton Rating w/ Ports M12, M10 Peterbilt EXPANSION VALVES - BLOCK TYPE ME 1600 1-1/2 Ton Rating ME 1618 1-1/2 Ton Rating 96-01 Freightliner Century Class ME 1611 1-1/2 Ton Rating w/ 2 Service Ports ME 1619 1-1/2 Ton Rating Main Unit Freightliner ME 1601 2 Ton Rating ME 1604 1-1/2 Ton Rating with R12 Port w/ Trinary Switch Port ME 1613 1-1/2 Ton Rating Freightliner Green Stripes Nick Type ME 1632 OE 327309 ME 1668 2 ton w/bypass Peterbilt, KW 549708BSM ME 1644 2 Ton Rating OE 540446BSM ME 1622 1-1/2 Ton Rating Volvo OE 20443850 ME 1690 2 Ton Rating International 3857948-C1 ME 1642 2 Ton Rating OE# VCCT1001838L ME 1684 OE# 85120289 ME 1672 2 Ton Rating OE# 85104197 ME 16106 2 Ton Rating PACCAR w/ M10, M12 Ports OE# 1000534258 ME 16101 1-1/2 Ton Rating w/ M10, M12 Ports OE# 1000463486 ME 1694 OE# W2073001 ME 1620 O-Ring Fittings, Male O-Ring, Equalizer Tube EXPANSION VALVES ME 1639 Peterbilt w/Inlet Screen EXTERNALLY EQUALIZED INTERNALLY EQUALIZED ME 1612 1-1/2 Ton Rating w/ 2 Service Ports ME 1612K Expansion Valve Kit ME 1612 w/ ME 0134B (2) ME 16128 Block-Slim-line Navistar 2516574-C91 ME 16100 1 Ton Rating PACCAR OE# Z9784001 ME 1614 2 Ton Rating Volvo; RE57575; 540056BSM ME 1678 OE# 3543-T4935001 ME 1615 1-1/2 Ton Rating Main Unit Gold Color APBN83-308231 ME 16126 Block-Flange Mack/Volvo 82795757

10 THERMOSTAT SWITCHES ME 1332 ME 1315 AIR OPERATED SWITCHES AIR SENSING SWITCH THERMISTER/TEMPERATURE COMPONENTS Fixed (Preset) Setting ME 1315 16" Capillary 28° - 35°F ME 1332 24" Capillary 31° - 39°F ME 1333 24" Capillary 34° - 44°F ME 1340 21" Capillary 31° - 40°F ME 1342 12" Capillary 31° - 39°F TRINARY SWITCHES HEATER VALVES & ACTUATORS ME 1550 3/8" Male Thread, Normally Open Fan Override BLOWER SWITCHES ME 1055 Blower Fan Switch Toggle Switch, Off-On-On-On Kenworth ME 1152 Blower Switch Harness, 5 terminal connector ME 1174 Blower Switch F-150/350; Sterling F4DZ-19986A; YH588 ME 1055H Blower Switch Harness (Fits 1050, 1055, 1056) ME 1150 Universal Blower Switch 5 Terminal - 3 Speed, 12/24V ME 1151 Universal Rotary Switch Short Thread 5 Terminal - 3 Speed, 12/24V ME 2010 Air Control Switch Black Toggle - Round Plastic Lever 1/8" Threads ME 2025 Air Switch Assembly Push-on Connectors ME 2385 Heater Electric Actuator Motor Mode Control - 2 Term. 4000/8000 Series International OE# 3542606-C1 ME 2258 Electric Heater Valve 5 Pin, Electronic 90° CCW Body, 5/8" to 5/8" hose end OE# 869948BSM ME 2355 Cable Control 5/8" to 5/8" Cable, Pull to Open 2003-07 Kenworth T300 OE# 869261BSMME ME 2398 Electric Heater Valve Assy. CW Body 4 Pin Actuator, 5/8" hose end PACCAR MA1685; OE# 868505BSM ME 2407 Heater Electric Actuator, 5-Pin Kenworth OE# 651291BSM ME 2383 Heater Actuator - 4 Pin Navistar OE# 2503207-C1 Mack OE# 7787-650694 ME 1340 ME 2005 Air Sensing Switch, NC Male 1/8"-27 NPTF Opens at 25psi ME 1307 Temp. Sensor for Evaporators Mack, Sprinter Van 2003-06, 2.7TD OE# 05103937AA ME 1347 Temperature Probe Switch Freightliner OE# BOA91619 BINARY SWITCHES ME 1511 Female Binary Switch M10 Thread ME 1513 M10 - R-134a ME 1514 Binary Switch, M10, NC ME 1515 Binary Switch M10 Thread ME 1512 R12 Female Binary, NO

11 ME 1310 ORANGE, Fan Override Switch, NC (uses harness #1559) M10 Threads, 2 Pin Open: 310psi, Close: 240psi PRESSURE SWITCHES ME 1499 High Pressure, NO, GREY Open: 250psi, Close: 325psi M10-1.25 Female RELAYS PRESSURE SWITCHES ME 1527 Universal Relay Harness 4T & 5T ME 1260 30/40 AMP, 12 volt Relay Kit - Weatherproof Seal w/Pigtail, w/o Diode, 5 wires, 5 Terminal, SPDT ME 1265A Relay w/ Resistor 70 AMP, 12v,4 Terminal Bus Applications ME 1266 5 Terminal 30/50 AMP, SPDT ME 1293 4 Terminal 70 AMP w/diode ME 1543 Bosch Mini-Relay Harness weatherproof, 5 wire (Fits: 1019, 1260, 1261, 1262, 1263, 1264) P/N ME 1598 Relay - Assortment P/N Description ME 1324 M10-1.25 High Pr., Binary, NC ME 1400 Freon Sensor/Navistar ME 1437 10mm Female, High Pr., NO ME 1438 12mm Female, Low Pr., NO ME 1439 M10 Female, High Pr., NC ME 1473 M10 Transducer (3 pin) ME 1489 M10 Female, High Pr., NC ME 1492 M10 Female, High Pr., NO ME 1493 M12 Female, Low Pr., NC ME 1498 M10 Female, High Pr., NC ME 1519 M12 Low Pr., NO P/N Description ME 1250 5 term., 40/30 amp, 12V ME 1251 5 term., 10/20 amp, 24V ME 1252 5 term., 30/40 amp, 12V ME 1261 5 term., 20/40 amp, 12V ME 1267 5 term., 20/10 amp ME 1268 5 term., 20/10 amp, NC Also Sold Individually ME 1472 High Press., NC, 2 pin (harness 1546) M10 Open: 355psi, Close: 250psi ME 1418 Clutch Cycling Switch, NO 12mm (R134a) Low Press. 2 Pin (uses harness #1562) Open: 25psi, Close: 45psi ME 1471 Low Press Sw, NO, 2pin (harness 1546) M12 Open: 13psi, Close: 30psi Peterbilt Pigtail for Peterbilt High/ Low Pressure Switches 2 wire Weatherpak Connector ME 1546 Harness Assembly ME 1299 Relay, SPDT w/ Resistor 5 terminal, 35/20 AMP Frghtlnr: OE# 23-13265-000 ME 1459 Red, High Pressure, NC Open: 285psi, Close: 240psi M10 Female OE# K301-382, -401 ME 1324 ME 1492 ME 1300 Relay, SPDT w/ Resistor 5 Terminal, 35/20 AMP Navistar 3519350C9; 301-1C-C-R1 ME 1522 Relay, 12v, 4 Pin S.P., Normally Open, 20 AMP Navistar Prostar 3600330-C1, 303-1AH-C-R1 ME 1523 Relay, 12v, 4 Pin S.P., Normally Open, 35 AMP Navistar Prostar 3600329-C1 ME 13502 Relay, 5 terminal 12v, 35/20 AMP Freightliner OE# 23-13265-01 ME 13503 Relay, 5 terminal 12v, 35/20 AMP International Navistar OE# 3571998-C1 ME 1374 Low Pressure Switch, NO Open: 3-9psi, Close 22-32psi M12-1.5 Threads International OE# 3839315-C1 ME 1375 Low Pressure M12-1.0 Threads Peterbilt OE# P27-61-42 ME 1400K HVAC Thermistor Kit Includes: (2) Freon Sensor #ME 1400 (2) Harness Repair Kit #ME 1544 (1) 3" Heat Shrink Tubing International OE# 2606229-C92 ME 15801 High Pressure Sw., M10 Fem., NC Open: 290psi, Close: 240psi Mack OE# 1MR2469M

12 INTERIOR DASH SWITCHES KENWORTH AUT577.59270 Electrical Switch Toggle, Dash Switch AUT577.59301 Electrical Switch SPDT, Momentary AUT577.59300 Electrical Switch SPST Gold Contacts, Cruise Control AUT577.59201 Electrical Switch Dome and Fan AUT577.59521 Mirror Switch Dual Heated Mirror PETERBILT AUT577.75611 Toggle Switch DPST Model 387, Usually use for Headlights and Clearance Lights, 2-Position Double Pole Single Throw with 4 Blades, Also used on Model 359 and Early Model 379 AUT577.75602 Toggle Switch Models 348, 349, 359, 362, 377, 378, 379, 2-Position, Single Pole, Single Throw with 2 Standard Blades AUT577.75604 Toggle Switch DPST RESISTORS WIRING COMPONENTS ME 1229 4 Speed 4 Terminal Resistor ME 1221 4 Speed , 4 Terminal Fits IH ME 1233 3 Speed 3 Terminal ME 1230 3 Speed 3 Terminal Resistor, Kysor ME 1248 4 Terminal Resistor Ford/Sterling ME 1243 5 Terminal Navistar 3562102C1 ME 1223P 4 Terminal Fits Peterbilt ME 1224 4 Speed 4 Terminal Fits Kenworth ME 1521 LPM Module/ Resistor 12 Volt, 4 Spade, 3 pin Navistar Prostar OE# 3626414-C1 ME 1558 Resistor 5 Terminal, 12v Mack 3543-H2480 ME 1582 Resistor, 5 Terminal Paccar OE# 651313BSM, CA1200 ME 1525 Trinary Switch Harness, 4 wires (Fits ME 1550, ME 1555, ME 1560, ME 1565) ME 1551 SD7H15 Clutch Coil Connector Metri-Pack 280 Heavy Duty Black Housing, 1 wire ME 1559 Pigtail for Pressure Switch (Fits ME 1310, ME 1403, ME 1404)

13 CONDENSERS ME 6202G - Aftermarket Grade 20" x 28-1/2" x 1" IN #8 MIO; OUT #6 MIO Kenworth T400, T600; K122-125 ME 6319G - Aftermarket Grade 19" x 33-1/4" x 5/8" (block connectors) Freightliner, Columbia w/Det 60 Series engine OE# 22-62271-000 ME 6283G - Aftermarket Grade 20" x 33-3/4" x 7/8" IN #8 MIO; OUT #6 MIO International 3504377-C1 ME 6273G - Aftermarket Grade 28" x 28" x 1-1/4" IN #8 MIO; OUT #6 MIO Peterbilt 18-04015 ME 6245AG - Aftermarket Grade (Alum. PF; Seals #0135) 16-1/4" x 31-1/2" x 7/8" Volvo VN 8084348; 20461065 Valeo 1210340 ME 6297G - Aftermarket Grade 19" x 33-5/8" x 5/8" (block connectors) Freightliner 1E5864, 1E6068 ME 6299 - OEM Grade ME 6299G - Aftermarket Grade 20-1/4" x 23-1/2" x 7/8" (pad fittings) Navistar 2508698-C92, 1E5114 ME 6300G - Aftermarket Grade 20-1/4" x 18-1/2" x 5/8" (pad fittings) Navistar 2507482-C92, 1E5001 ME 6290G - Aftermarket Grade 19-5/8" x 29" x 7/8" IN #8 MIO; OUT #6 MIO MACK OE# 210RD510M ME 6011 9" x 27-1/2" x 1-1/8" IN #8 MIO; OUT #6 MIO Kenworth T450, T600; K122-93 ME 6229G - Aftermarket Grade 20" x 31-1/2" x 7/8" IN #8; OUT #6 Tube-0 Freightliner C112,C120 Century Class N83-306275, 22-42084-002 ME 6288G - Aftermarket Grade 19-1/2" x 24" x 3/4" 4000, 7000, 8000 Series (pad connectors) IHG/Navistar 2505650-C92 ME 6289G - Aftermarket Grade 23-1/4" x 31-7/8" x 3/4" IN #8 MIO; OUT #6 MIO Mack 25498661, 210RD418 ME 6320G - Aftermarket Grade 20-3/8" x 27-1/4" x 5/8" (block connectors) Freightliner M2 OE# 22-62390-000; A22-66842-000 ME 6327G - Aftermarket Grade 21-1/8" x 31-3/8" x 3/4" IN #8 MIO; OUT #6 MIO (driver side) Mack Granite OE# 210RD427 ME 6331G - Aftermarket Grade 21-1/8" x - 3/8" x 3/4" #6, #8 MIO Fittings (passenger side) MACK OE# 210RD428 ME 6066 10" x 27-1/2" x 1-3/4" IN #8 MIO; OUT #6 MIO Freightliner w/ Cat. Eng. A22-24885-000 ME 6200G - Aftermarket Grade 10" x 27-1/2" x 1-3/4" IN #8 MIO; OUT #6 MIO Freightliner FLD, Classic XL A22-32466-001 ; BEHR #8819757 ME 6292G - Aftermarket Grade 24-1/4" x 29-1/2" x 11/16" (pad fittings) Peterbilt 2005 OE# 1E5611 ME 6332 - OEM Grade ME 6332G - Aftermarket Grade 19" x 33-5/8" x 3/4" (block connectors) 06-07 Columbia, Coronado OE# 1E5865 , 1E6069

14 ME 6665 10" x 10" x 2-5/8" (Tube & Fin) MACK OE# 7787-869224 EVAPORATORS ME 6679 11" x 10-7/16" x 2-5/8" (Tube & Fin) PETERBILT 3X010018 ME 6683 6-5/8" x 12-1/16" x 2-5/8" (Plate & Fin) (Aluminum) #8, #12 Bead Ends (incl. exp. vlv., uses #6, #12 o’rings) NAVISTAR PROSTAR 3670125-C91; 3670132-C1 ME 6684 7" x 10-3/8" x 2-5/8" (Plate & Fin) PAD w/ Block Viv #1678 Mack Granite 2008 w/ BEHR oe# 3543-R0442001 ME 6609 10" x 13" x 2-5/8" (Tube & Fin) 8 x 8 Bead End Navistar 5000/9000 OE 1699950-C1 ME 6601 12" x 8" x 3" Kenworth 151328; NA1090 ME 6655G 8-3/4" x 8-1/8" x 2-7/8" (Plate & Fin) (Less Plate - Re-use Original Plate) Peterbilt OE P93CAB1501-01S ME 6598 8" x 12-5/8" x 3-1/8" (Tube & Fin) Mack MC, MR Series OE# 4379-RD21381-0 ME 6345G - Aftermarket Grade 22-1/8" x 34-1/2" x 5/8" (block connector) 2009 Freightliner OE# A22-7246-000 ME 6357G - Aftermarket Grade 15" x 31" x 3/4" (pad fittings) Mack Vision 07-08 OE# 210RD517M ME 6368G - Aftermarket Grade 20-1/8" x 23-5/8" x 5/8" (pad fittings) International 5500i, 5600i, 5900i Series OE# 2585373-C2 ME 6370G - Aftermarket Grade 20" x 25" x 5/8" (pad fittings) Kenworth OE# N4783001 ME 6372G - Aftermarket Grade 32-3/4" x 15-3/4" x 5/8" (pad fittings) Navistar ProStar OE# 2601444-C91, 2601445-C91 ME 6390G - Aftermarket Grade 18-1/2" x 31-1/4" x 3/4" Parallel Flow (pad fittings) Navistar ProStar O.E. #2604851-C91 ME 6393 19-3/4" x 23-1/2" x 3/4" (pad fittings) International Navistar OE# 2601796-C91 ME 6395 20" x 33-3/4" x 5/8" (pad -sealing washers) PACCAR OE# F31-6200; 29206001 ME 6427 16-1/4" x 31-1/2" x 7/8" Parallel Flow (PAD Ftgs.) Volvo Trucks OE# 22368057 ME 6358G - Aftermarket Grade 14" x 33" x 3/4" (#6 & #8 pads) KW T300, Peterbilt 365/379/387/388/389 2008 OE# M3659001 ; M3660002 ME 6359G - Aftermarket Grade Peterbilt 367 2008 19" x 33" 3/4" (pad fittings) OEM# M3609001; N4778001 ME 6457 20" x 33-1/4" x 58" Parallel Flow, Pad Manifold Navistar Trucks 2518753C91

15 HEATER HOSE FITTING HEATER CORES ME 6836 8" x 12" x 2-1/2" In - 5/8" Out - 5/8" Kenworth C500 110640, MC1005 ME 6886 7-7/8" x 8" x 2" In - 5/8" Out - 5/8" Clip type tube (use o-rings #0028) Kenworth OE# 108263 We Stock a Full Line of Water Pumps ▪ Belt Tensioners Antifreeze ▪ Hose ▪ Filters EVAPORATORS, CONTINUED ME 2610 5/8" O.D. ME 2611 3/4" O.D. Heater Hose Splicer P/N Size Color Strength PG AF9101 1 Gallon Purple (Pink) Full PG AF9155 55 Gallon Purple (Pink) Full PG AF9501 1 Gallon Purple (Pink) 50/50 PG AF9555 55 Gallon Purple (Pink) 50/50 P/N Size Color Strength PG AFC13000/F 1 Gallon Red Full PG AFC13000-55/F 55 Gallon Red Full PG AFC13100/F 1 Gallon Red 50/50 PG AFC13100-55/F 55 Gallon Red 50/50 SCA PRE-CHARGED PRESTONE COMMAND® HEAVY DUTY COOLANT Also Offering Light Duty & RV Coolants! Prime® Conventional “Green” Coolant Also Available EXTENDED LIFE COOLANT P/N Size Color Strength PG AF9701 1 Gallon Red Full PG AF9755 55 Gallon Red Full PG AF9901 1 Gallon Red 50/50 PG AF9955 55 Gallon Red 50/50 • Nitrited organic acid technology (NOAT) • Silicate, phosphate and borate-free formulation • Long-lasting inhibition • CAT EC-1 compatible for any heavy duty engine • Complete liner pitting and corrosion protection; protects aluminum and all other engine metals • Compatible with all heavy duty NOAT formulations • 1,000,000 MILE / 20,000 HOUR SERVICE LIFE* • Cor-Guard™ Increases Uptime • Extended Life Coolant (ELC) • NON-2EH (OAT) Formulation • Meets Cummins® and Detroit Diesel® Performance Requirements Prestone Command® HD Nitrite Free ELC with Cor-Guard™ is intended for use and compatible with ANY nitrite free HD Organic Acid Technology (OAT) coolant in ANY diesel powered commercial vehicle engine or other engine cooling system metals. NITRITE FREE ELC WITH COR-GUARD™ ANTIFREEZE/COOLANT NEW NITRITE FREE NON-2EH (OAT) FORMULATION *Provide Extended Life protection which meets the vehicles manufacturer recommended change intervals for all DOT Truck Classes, including up to 1,000,000 miles for Class 8 vehicles. ME 6687 8-3/4" x 11-7/8" x 1-1/2" #8, #10 Bead Ends Peterbilt, Main 330 thru 389; OE# 3S011453 ME 6688G (Aftermarket Grade) 6-3/4" x 8-7/8" x 3" IN: #8 Female O’ring / OUT: #10 Bead End w/expansion valve Peterbilt, Sleeper OE# 3X010151 (uses #4318 Fitting Adapter Kit ME 6706 8-1/2" x 10" x 2-3/4" PAD (supplied w/expansion valve) In/Out: Bead fittings PACCAR O.E.# W2078001 ME 6715 8-1/2" x 12" x 1-5/8" (Plate-Fin) In/Out: PAD Peterbilt OE# 100473781

16 A/C HOSE & FITTINGS Galaxy® G4826 SAE J2064 / Air Conditioning G4826 Related Fittings Compressor O-Ring Tube, Female, 90° Elbow Picture Not Available Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-COTF90-0810 - 13/32 1-14 - ME 4437S 5/8 1-14 Flareless Tube, Male Machine # Crimp Manual # Crimp Hose ID Inch Thread Size - ME 4490S 5/16 5/8-18 O-Ring Insert Male Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OIM-0808 ME 4471S 13/32 3/4-16 GX AC-OIM-1010 ME 4472S 1/2 7/8-14 O-Ring Tube, Female, Swivel Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTF-0606 ME 4402S 5/16 5/8-18 GX AC-OTF-0608 ME 4431S 5/16 3/4-16 GX AC-OTF-0808 ME 4403S 13/32 3/4-16 GX AC-OTF-1010 ME 4404S 1/2 7/8-14 - ME 4432S 5/8 7/8-14 GX AC-OTF-1212 ME 4405S 5/8 1 1/16-14 Hose Mender Machine # Crimp Manual # Crimp Hose ID Inch - ME 4479S 13/32 - ME 4480S 1/2 - ME 4481S 5/8 O-Ring Tube, Female, Swivel, 45° Elbow Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTF45-0808 ME 4407S 13/32 3/4-16 GX AC-OTF45-1010 ME 4408S 1/2 7/8-14 GX AC-OTF45-1212 ME 4405S 5/8 1 1/16-12 O-Ring Tube, Female, Swivel, R134a Valve (Also available with switch port) Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTF134V-0606 ME 4502S 5/16 5/8-18 Application: Recommended for R134a and R12 refrigerants in automotive, heavy-duty truck, construction and agricultural air conditioning systems Inner Tube: Chloroprene Barrier: Nylon Reinforcement: Two-spiral polyester Cover Compound: Black EPDM Temperature Range: -22°F to 257°F (-30°C to 125°C) Fitting Reference: All fittings compatible with the G4826 hose family P/N Hose Size Inch Max. Working Pressure Min. Bend Inch Min. Burst PSI GX G4826-06X250RL 5/16 500 0.6 2000 GX G4826-08X250RL 13/32 500 1.0 2000 GX G4826-10X250RL 1/2 500 1.3 2000 GX G4826-12X250RL 5/8 350 2.0 1750 O-Ring Tube, Female, Swivel, R134a Valve, 45° Elbow (Also available with switch port) Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTF134V90-0606 ME 4510S 5/16 5/8-18 - ME 4512S 1/2 7/8-18 - ME 4513S 5/8 7/8-14 GX AC-OTF134V90-1212 - 5/8 1 1/16-16 O-Ring Tube, Female, Swivel, 90° Elbow Machine # Crimp Manual # Crimp Hose ID Inch Thread Size - ME 4410S 5/16 5/8-18 - ME 4438S 5/16 3/4-16 - ME 4411S 13/32 3/4-16 - ME 4436S 1/2 3/4-16 GX AC-OTF90-1010 ME 4412S 1/2 7/8-14 - ME 4439S 1/2 1 1/16-14 - ME 4437S 5/8 7/8-14 GX AC-OTF90-1212 ME 4413S 5/8 1 1/16-14 O-Ring Tube, Male, Swivel, 90° Elbow Machine # Crimp Manual # Crimp Hose ID Inch Thread Size - ME 4474S 5/16 5/8-18 - ME 4475 13/32 5/8-18 GX AC-OTM90-0808 - 13/32 3/4-18 GX AC-OTM90-1010 ME 4476S 1/2 7/8-18 GX AC-OTM90-1212 ME 4473S 5/8 1 1/16-16

17 Schrader O-Ring Fittings O-Ring Tube, Male, Swivel, 45° Elbow Tube-O Ring Compressor R134a Port O-Ring Fitting Tube-O Ring Compressor R134a Port Steel Beadlock Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTM45-0606 - 5/16 5/8-18 GX AC-OTM45-0808 - 13/32 3/4-18 SAE 45° Flare, Female, Swivel, 90° Elbow Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-SFFX90-0606 - 5/16 5/8-18 SAE 45° Flare, Female, Swivel Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-SFFX-0808 - 13/32 3/4-16 GX AC-SFFX-1010 - 1/2 7/8-14 O-Ring Tube, Male, Swivel Machine # Crimp Manual # Crimp Hose ID Inch Thread Size GX AC-OTM-0606 ME 4389S 5/16 5/8-18 - ME 4388S 5/16 11/16-16 GX AC-OTM-0808 - 13/32 3/4-18 GX AC-OTM-1010 - 1/2 7/8-18 ME 5513 #8 O-Ring Discharge w/16mm ME 5514 #10 O-Ring Suction w/13mm ME 5529 #10 O-Ring Suction w/13mm Port (Low Side) PAD MANIFOLD FITTINGS R134A SERVICE CAPS Color: Blue with L (Low Marking) Applications: Bridgeport Piedmont OEM R134a 13mm Port Bridgeport Piedmont RetroFit 13mm Adapter Refrigeration Sales R134a RetroFit 13mm Adapter Color: Blue with L (Low Marking) Applications: Bridgeport Piedmont OEM R134a 13mm JRA Port Color: Blue Applications: Aeroquip OEM R134a 13mm Port Aeroquip Piedmont RetroFit 13mm Adapter Frig-C Low Side R134a RetroFit Adapter Color: Black Applications: Service Port Cap 13mm - R134a Color: Black Applications: Service Port Cap 16mm R134a Eaton SSV Type Caps Color: Red with H (High Marking) Applications: Bridgeport Piedmont OEM R134a 16mm Port Bridgeport Piedmont RetroFit 16mm Adapter Refrigeration Sales R134a RetroFit 16mm Adapter Color: Red with H (High Marking) Applications: Bridgeport Piedmont OEM R134a 16mm JRA Port ME 5533 10 per box ME 5574 10 per box ME 5534 10 per box ME 5575 10 per box A/C HOSE & FITTINGS, CONTINUED ME 5433 #10 Beadlock Suction w/13mm ME 4204S Kenworth, Peterbilt Pad/Tube #10 MIO #10 Compressor (Suction) Fits into slot of: #4203S ME 4203S Kenworth, Peterbilt Pad/Tube #8 MIO #8 Compressor (Discharge) #10 Slot for #4204S, #4205S ME 5587 10 per box ME 5579 10 per box ME 5580 10 per box

18 O-RINGS ME 4808 (100 pcs) GM Capillary Tube HNBR (green) ME 0138 (10 pcs) Navistar- Metal gasket w/rubber insert (red) - Discharge ME 0140 (10 pcs) Freightliner Compressor 1-1/8" O.D., 9/16" I.D. Stat Seal (red) ME 0141 (10 pcs) Freightliner Evaporator #10 Stat Seal (red) 5/16" O.D., 9/16" I.D. (Fits #1619 exp vlv suction side) ME 0011 (20 pcs) ME 4811 (100 pcs) #6 Hose Fitting Seltec TM15, DKS13/15 Oil Plug Ford #6 Springlock Fitting HNBR (green) ME 0013 (20 pcs) ME 4813 (100 pcs) #8 Hose Fitting #8 Ford Springlock HNBR (green) ME 0015 (20 pcs) ME 4815 (100 pcs) #10 Hose Fitting Ford #10 Springlock; CCI/Tecumseh Tube-O HNBR (green) ME 0017 (20 pcs) ME 4817 (100 pcs) #12 Hose Fitting Ford #12 Springlock; VIR Exp Vlv (Lower), Evap Outlet, Comp Suction Line #4 #6 #8 #10 #12 ME 0149 STAT SEAL SINGLE JOB SEAL KIT Qty. P/N Description 2 ea. ME 0130 #6 Stat Seal 2 ea. ME 0131 #8 Stat Seal 2 ea. ME 0140 Compressor Seal 2 ea. ME 0141 #10 Stat Seal 2 ea. ME 0142 #12 Stat Seal ME 0169 O-Ring and Gasket Kit Navistar Suction & Discharge O-rings & Gaskets #6 o-ring (1 ea), #8 o-ring (4 ea), #10 o-ring (3 ea), #ME 0136 (2 ea), #ME 0137 (2 ea), #ME 0138 (5 ea), #ME 0139 (2 ea) ME 0199 SINGLE JOB O-RING KIT Qty. P/N Description 1 ea. ME 0008 Capillary Tube 7 ea. ME 0011 #6 O-Ring 6 ea. ME 0013 #8 O-Ring 4 ea. ME 0015 #10 O-Ring 1 ea. ME 0017 #12 O-Ring ME 0130 (10 pcs) #6 Stat Seal (red) 5/8" O.D., 5/16" I.D. metal washer w/rubber insert ME 0131 (10 pcs) #8 Stat Seal (red) 3/4" O.D., 7/16" I.D. metal washer w/rubber insert ME 0136 (10 pcs) Navistar- WG head - Discharge 5/8" O.D., 3/8" I.D. (yellow) ME 0137 (10 pcs) Navistar- WG head - Suction 3/4" O.D., 5/8" I.D. (yellow) ME 0139 (10 pcs) Navistar- Metal gasket w/rubber insert (red) - Suction ME 0142 (10 pcs) Freightliner #12 Stat Seal (red) 1" O.D., 11/16" I.D. (Fits #1619 exp vlv suction side) ME 0155 Navistar Discharge Kit #0136 & #0138 ME 0156 Navistar Suction Kit #0137 & #0139 ME 0160 Navistar Discharge & Suction Kit #0155 & #0156 ME 0149 (10 pcs) O-Rings, Gaskets & Seals #0130 #6 Stat Seal, #0131 #8 Stat Seal, #0141 #10 Stat Seal, #0140 Compressor Seal, #0142 #12 Stat Seal ME 0174 (10 pcs) Mack/Volvo Trucks Drier O-Ring 25mm OD, 19mm ID ME 0124 (10 pcs) Volvo WV Head/Suction O-Ring 1-1/4" OD, 1" ID ME 0129 (10 pcs) Volvo WV Head/Discharge O-Ring 1-1/8" OD, 7/8" ID Used with #0136 and #0137 yellow o-rings Orange ME 1652 Ford .057" Red ME 1654 Ford/Peterbilt .062" Purple ME 1662 Navistar 3548044C1 Black White ME 1663 Ford E-Series .072" ORIFICE / EXPANSION TUBES Blue ME 1651 Ford .067" White ME 1650 GM .072" International Orifice Inlet Tube ME 1674 (uses #1662 orifice tube; o’rings #0136 & #0138) OE# 3542578C2, BOA80-305-00-939 O-ring & Gasket Kit #0155 (2)

19 ME 8974 Most Current, Late Model Truck, O-Ring Servicing Kit ASSORTMENT KITS Qty. Part # Description 20 ea ME 0011 No. 6 O-Ring 20 ea ME 0013 No. 8 O-Ring 20 ea ME 0015 No. 10 O-Ring 10 ea ME 0017 No. 12 O-Ring 10 ea ME 0121 GM compressor O-Ring 5 ea ME 0136 Navistar WG Head/Discharge O-Ring 5 ea ME 0137 Navistar WH Head/Suction O-Ring 2 ea ME 0138 Navistar Gasket/Small 2 ea ME 0139 Navistar Gasket/Large ME 8988 Master O-Ring Service Kit - R12/R-134a Compatible. *O-Ring is compatible with R-12 & R-134a **Also available in 100 pc. set #0121 Qty. Part # Description 10 ea. ME 4808 O-ring-Capillary Tube 10 ea. ME 4811* O-ring-#6 Hose Fitting 10 ea. ME 4813* O-ring-#8 Hose Fitting 10 ea. ME 4815* O-ring-#10 Hose Fitting 10 ea. ME 4817* O-ring-#12 Hose Fitting 20 ea. ME 4821** O-ring-GM Suction/Discharge 4 ea. ME 5574 Tescumesh/York Flange Gasket 10 ea. ME 8915 Schrader Core 10 ea. ME 8781 Charging Hose Seals Qty. Part # Description 10 ea. ME 8782 Valve Core Depressor 10 ea. ME 5531 1/4" Service Cap 10 ea. ME 5532 3/16" Service Cap 10 ea. ME 5576 Rotalock Teflon Seal 3 ea. ME 5578 Service Valve Cap 4 ea. ME 5510 GM Clutch Lock Nut 3 ea. ME 5536 GM Shaft Key 3 ea. ME 5537 Sanden Shaft Key 3 ea. ME 5538 Tecumseh/York Key Qty. Part # Description 5 ea ME 0140 Freightliner Suct/Disch Stat-Seal 5 ea ME 0126 Freightliner Slimline #6 5 ea ME 0127 Freightliner Slimline #8 5 ea ME 0128 Freightliner Slimline #10 5 ea ME 0130 Freightliner Stat-Seal #6 5 ea ME 0131 Freightliner Stat-Seal #8 5 ea ME 0141 Freightliner Stat-Seal #10 5 ea ME 0129 Volvo WV Head/Discharge O-Ring 5 ea ME 0124 Volvo WV Head/Suction O-Ring ME 8989 R12/R-134a Fitting O-Ring Kit Complete O-Ring assortment for standard size hoses. Qty. Part # Description 10 ea ME 0008 No. 4 O-ring 10 ea ME 0011 No. 6 O-ring 10 ea ME 0013 No. 8 O-ring Qty. Part # Description 10 ea ME 0015 No. 10 O-ring 10 ea ME 0017 No. 12 O-ring 5 ea ME 0121 Service Port O-ring ME 8993 Master Deluxe O-Ring and Sealing Washer Assortment Kit Qty. Part # Description 10 ea ME 0011 #6 O-Ring 10 ea ME 0013 #8 O-Ring 10 ea ME 0015 #10 O-Ring 10 ea ME 0117 Seltec Suct./Disch. Manifold O-Ring 2 ea ME 0130 #6 Stat Seal 2 ea ME 0131 #8 Stat Seal 2 ea ME 0136 Navistar WG Head/Discharge O-Ring 2 ea ME 0137 Navistar WH Head/Suction O-Ring 2 ea ME 0138 Navistar Gasket/Small 2 ea ME 0139 Navistar Gasket/Large 2 ea ME 0140 Stat Seal (compressor) Qty. Part # Description 2 ea ME 0141 #10 Stat Seal (evaporator) 2 ea ME 0142 #12 Stat Seal 2 ea ME 5533 13mm Port Cap 2 ea ME 5534 16mm Port Cap 2 ea ME 5574 13mm JRA Port Cap 2 ea ME 5575 16mm JRA Port Cap 2 ea ME 5579 13mm Eaton Port Cap 2 ea ME 5580 16mm Eaton Port Cap 2 ea ME 8915 1/4" Schrader Core 2 ea ME 8916 M6 Schrader Core 2 ea ME 8925 M8 Eaton Core 2 ea ME 8926 M10 Schrader Core 2 ea ME 8955 M8 High Flow Schrader Core ME 8995 Freightliner (Later Models) - Slimline and Stat Seal Assortment Qty. Part # Description 10 ea. ME 0126 Slimline Seal #6 10 ea. ME 0127 Slimline Seal #8 10 ea. ME 0128 Slimline Seal #10 10 ea. ME 0130 Stat Seal #6 Qty. Part # Description 10 ea. ME 0131 Stat Seal #8 10 ea. ME 0140 Stat Seal (compressor) 10 ea. ME 0141 Stat Seal #10 (evaporator) 10 ea. ME 0142 Stat Seal #12

20 Kit Contains: • TP-1140 rugged carrying case • 120884 8 oz. GLO-AWAY™ dye cleaner • TP-9940 fluorescence-enhancing glasses • TP-8680 super high intensity OPTIMAX™ LED flashlight with AC charger • TP-3900-0008 8 oz. dye for coolant & truck/trailer/auto body leaks • TP-3400-0008 8 oz. All-In-One dye for oil, fuel ATF, power steering & hydraulic leaks • TP-9870 (2) 1/2 oz. EZ-Ject universal dye cartridges • 120687 R-134a AC&R hose & R-12 adapter/purge fitting • TP-9845 EZ-Ject dye injector • Dye service underhood labels LEAK DETECTORS TP TP-8697HD Heavy Duty Ez-Ject™ Leak Detection Kit HEAVY DUTY CABIN AIR FILTERS OEM # Application Location LUBER-FINER MEI Freightliner BOA91559 Columbia (All) Coronado (All) Century (1998-up) Cascadia (ALL) Under hood on firewall pass side behind air cleaner 10.70" x 10.63" x 0.98" LF CAF24003 ME 7998 Freightliner 2244665000 Century (1994-1997) Under dash passenger side 10.63" x 10.63" x 0.79" LF CAF24004 - Freightliner BOA91595 Century (1998-up) Passenger side sleeper 7.87" x 6.30" x 0.71" LF CAF24011 - Freightliner 36000006 M2 (2004-) Passenger side under dash 8.60" x 8.35" x 0.98" LF CAF24016 - International 2506656C1 Durastar, Lonestar, Prostar, Transtar, Workstar Under hood passenger side on firewall 12.48" x 7.21" x 0.98" LF CAF24005 ME 7997 International 498144C1 4300 (1981-1998), 9670 (1981-1998) Under passenger seat 13.39" x 12.60" x 0.79" LF CAF24008 ME 7990 International 1699956C1 5000 Series, 9000 Series See owner's manual 13.61" x 9.97" x 0.60" LF CAF24013 ME 7987 Kenworth 525507 T2000 (All) Under hood center firewall passenger Side 13.98" x 10.08" x 0.68" - ME 7996 Kenworth 534510BSM T370, T600 12" X 3" X 7/8" - ME 7957 Mack/ Volvo 85112361 Woven Fabric Pleated Style 10" X 9 7/8" X 1" - ME 7956M Mack 7787-525784 Granite 2002-05 101/4" X 11" X 1/2" - ME 7973 Paccar and Navistar X1987001, 4070948C1 Filter w/o frame 8 7/8" x 7 7/8" x 1 3/16" - ME 7847G Peterbilt 5X000180 357,379,385,388 (2002-on) Under dash passenger side 10.13" x 6.78" x 0.79" LF CAF24006 - Peterbilt 5X010007 330,335,340,357, 365,367, 378, 379,384,386 (1998-on) Under dash passenger side 11.94" x 8.12" x 1.06" LF CAF24012 - Peterbilt 525838BSM 101/4" X 13 3/4" X 1" - ME 7972 Peterbilt 5X000180, 5X000190 10 1/4" X 7" X 3/4" - ME 7980 Sterling F6HZ19N619AA Acterra, A-Line and L- Line Under dash passenger side 8.54" x 6.18" x 1.34" LF CAF24014 ME 7971 Volvo 20435801 VN, VNL, VHD, VNM, VT Series Under hood on firewall passenger side 12.64" x 9.17" x 1.18" LF CAF24000 Donaldson# P606555 ME 7979 Volvo 8089705 VN Series (1998-2002) Under hood passenger side 11.42" x 4.72" x 1.73" LF CAF24002 ME 7982 Western Star RD384160 4900 (1995-up) Under dash passenger side 11.93" x 5.45" x 0.87" LF CAF24017 Western Star RD3-8777-0 Fits front cab, not sleeper 11 1/2" X 4 7/8" X 3/4" - ME 7960 Western Star 60015-3421; RD3-9157-0; RD3-9155-0 Non-Hepa type (foam with metal frame, 2 pack) 9" x 7 3/4" 1" - ME 7953 FRESH AIR FILTERS Kenworth Conv. 1986-2014 UP ME 7840 - Black ME 7840C - Chrome ME 7840 - Element Only

21 Includes: • TP-9749 EZ-Shot dye injection gun • TP-9747 hose/coupler for R-134a systems with R-12 adapter/purge fitting • TP-9770-0108 - 8 oz. universal A/C dye cartridge for servicing up to 64 vehicles TP TP-9790 EZ-Shot™ Universal A/C Dye Injection Kit TP TP9870-CS INJECTORS & KITS FLUORESCENT DYES TP TP-3840-0008 Universal/POE Dye 8 oz. TP TP-3840-0601 Universal/POE Dye 1 oz. TP TP9870-CS Universal / Ester Ez-Ject A/C Dye 0.5 oz. (R-1234yf Compatible) LD R134A30UV 30# Cylinder R-134a-UV Refrigerant with UV Leak Detection Dye Now Available Through Robinair® Robinair® CoolGuard™ Plus: Preventive Maintenance and Extended Warranty Robinair® CoolGuard™: Preventive Maintenance only contract *See Your Sales Rep. for More Details* MAINTENANCE PARTS • SYSTEMS & COMPONENTS RB 34788NI RB 34724 Filter-Drier RB 13172 Maintenance Kit RB 17499 Vinyl Dust Cover RB 34700 RB 34234 RB 34430 Quick Change Recycling Filter-Drier RB 34724 Spin-On Recycling Filter-Drier (Refer to owners manual for correct filter-drier for your station) RB 34750 50 lb. Tank for R-134a RB 17492 Vinyl Dust Cover RB 17121 30 lb. Refillable Tank for R-12 RB 34102 30 lb. Refillable Tank for R-134a RB 34724 Spin-On Recycling Filter-Drier RB 17495 Vinyl Dust Cover • Complete design, incorporated on a single chip, creates a compact, lightweight tool • Laser point • Innovative optical lens RB TIF7610 IR Thermometer PRO THERMOMETERS A/C Dye Cartridges ME 8476 8 oz. Refilled and disposable. One ounce for die treat up to 5-8 vehicles. RB 17800C RB 34800 RB 17677 Heavy Duty Recycling Filter-Drier RB 17506 50 lb. Tank with Float Switch RB 17812 Vinyl Dust Cover RB 17121 30 lb. Refillable Tank for R-12 RB 34102 30 lb. Refillable Tank for R-134a RB 34724 Spin-On Recycling Filter-Drier RB 17490 Vinyl Dust Cover RB 17622 Sealant Remover • Connect between vehicle & A/C service equipment • Prevents damage to your service equipment • Keeps refrigerant supply clean RB 17700A RB 17641 Hose Kit RB 17622 Replacement Filter RB 17623 Replacement Filter Pack, R17622 RB 34430 Quick Change Recycling Filter-Drier RB 17506 50 lb. Tank for R-12 RB A17577 Moisture Indicator RB 17495 Vinyl Dust Cover • High & low pass filters with audible alarms for out-ofrange measurements • Visual low battery indicators; uses two “AAA” batteries

22 • Can recover, recycle, evacuate and recharge multiple refrigerants, all in one fast and continuous operation through one hook-up. It’s ideal for mass transit vehicles, buses, refrigerated trailers or containers and other applications that use refrigerants other than R-134a and not typically found in mobile vehicle applications. • Recover, recycle, evacuate and recharge R-12, R-134a, R-22, R-404A, R-407C, R-452A, R-448A, R-449A and many other medium-pressure and high-pressure refrigerant blends. RB 17800C Recover, Recycle, Evacuate and Recharge Large-capacity A/C Systems Schrader Valves and Tools ME 8915 1/4"- Replacement Valve Core R12/R134a Service Port OAL 3/4" top to bottom (10 per box) Universal Standard Size 7/32" OD ME 8916 M6 - High Flow Removal Tool R134a; Japanese JRA, OAL 3/4" top to bottom (10 per box) 9/32" OD ME 8919 R12/R134a Schrader Core Remover Universal ME 8925 M8 - Eaton 13mm SSV High Flow Low Side Service Port, OAL 7/8" top to bottom (10 per box) 1/4" OD ME 8926 M10 - Eaton 16mm SSV High Flow High Side Service Port OAL 7/8" top to bottom (10 per box) 11/32" OD ME 8938 R12/R134a Schrader Valve Core Kit Qty. P/N Description 2 ea. ME 8914 GM Large Bore 10 ea. ME 8915 Standard Flow Valve Core 2 ea. ME 8916 JRA Import Valve Core 2 ea. ME 8925 Eaton 13mm SSV High Flow 2 ea. ME 8926 Eaton 16mm SSV High Flow 2 ea. ME 8955 M8 High Flow Core ME 8927 R134a Heavy Duty Core Removal Tool, Standard Size and Eaton SSV E-Z Clip Size. ME 8955 Volvo M8 - High Flow Schrader Valve Core M24x1.0 thrd, OD Base 7/32", OAL 7/8" top to bottom (10 per box) 9/32" OD MAINTENANCE PARTS • SYSTEMS & COMPONENTS RB 17580 Closed Loop Circulates solvent continuously through components (adapters are needed) Pulsing Action Loosens dirt, corrosion and other debris; by switching the hoses, you can also back flush Air Agitation Needle Valve Bubbles air into liquid stream to enhance cleaning action Hose Adapters Contains adapters to mate with 1/4" flare and 3/8" quick dis-connect fitting kits Sight Glass Tank level sight glass for easy filling Makes flushing of lines, evaporators and condensers fast and easy! The flush gun uses dry shop air to pressurize the solvent. The process thoroughly cleans the part, removing oil and any refrigerant contaminants and residue. The attached nozzle directs the flow of solvent without spray-back. RB 17595 ME 8812A Quart • Environmentally safe • Multi-refrigerant compatible • OE tested/approved A/C SYSTEM FLUSHER A/C FLUSH GUN RB 17609 Quart Gives you the cleaning power to flush particulates and system lubricant from A/C and refrigeration lines, evaporators, and condensers. An ideal substitute for CFC-113, it has excellent cleaning properties and good evaporation rate. Compatible with all CFC, HCFC, and HFC refrigerants. Meets ANSI/ASHRAE 97-1933. CASTROL A/C FLUSH OIL BASE FLUSHING SOLVENT See Us for A/C Flush Procedures Vacuum Pumps VacuMaster® Single Stage Vacuum Pumps RB 15115 1.5 CFM Vacuum Pump RB 15310 3 CFM Vacuum Pump RB 15510 5 CFM Vacuum Pump VacuMaster® 2-Stage Vacuum Pumps RB 15150 1.5 CFM Vacuum Pump RB 15300 3 CFM Vacuum Pump RB 15500 5 CFM Vacuum Pump CoolTech® Vacuum Pumps RB 15434 4 CFM Vacuum Pump RB 15600 6 CFM Vacuum Pump
