LIMITED SECURITY RACKS (LSR) ALUMINUM TOOL BOXES BAWER BOXES - Distributed by Merritt Dyna-Light LSR - Pictured w/ MER328 Kit Base Unit LSR MER317 Dyna-Light 68" x 70" Radius Corner MER318 Dyna-Light 68" x 76" Radius Corner MER320 Dyna-Light 68" x 80" Radius Corner Options Available - Add To Your LSR Base Unit MER328-1 Deluxe Option Kit - Full Tray with Two Locking Chain Racks LSR MOUNTING KIT - DYNA-CLAMP MER324 Dyna-Clamp Kit (17" U-bolts) For Frame Rails 11" Deep or Less MER325 Dyna-Clamp Kit (21" U-bolts) For Frame Rails Over 11" • Dyna-Tube Extrusion, aerodynamic radius corner shape, high strength/low weight • Offset design to accommodate the new style exhaust systems • 4" Foot assembly provides increased trailer clearance, easier mounting & durability • New T-Beam extrusion provides for a better weight to strength ratio, for improved load resistance • 5" uprights require less mounting space and give unparalleled load resistance • Great for storage - Internal shelves and chain hangers are popular options • Keep your storage items out of the weather and out of sight MER324 CATALOG NUMBER 09 www.midwestwheel.com NLINE www.midwestwheel.com Order NLINE™ Diamond Plate Single Door Double Door 24" x 24" x 24" MER214 - 24" x 24" x 48" MER220 MER222 24" x 24" x 60" MER224 MER226 Smooth Single Door Double Door 18" x 18" x 48" MER209 - 24" x 24" x 24" MER213 - 24" x 24" x 30" MER215 - 24" x 24" x 48" MER219 MER221 24" x 24" x 60" MER223 MER225 MER117 For 18" Deep Tool Box MER118 For 24" Deep Tool Box MER621 E-Z Mounting Kit for 18" Tool Boxes • Constructed of high strength / low wight aluminum • Polished stainless steel T-handle latches with locks • Piano style door hinge • Doors available in smooth finish or diamond plate • All smooth doors are polished to a # 8 grade for an exceptional appearance • Vertical angle is high strength alloy and 1/4" thick • Steel for strength and low cost, Zinc Plated for lasting good looks! • Lightweight design - 117 only 18 lbs, 118 only 25 lbs. Black Steel Single Door 18" x 18" x 18" MER3980 18" x 18" x 48" MER3984 24" x 24" x 24" MER3989 24" x 24" x 48" MER3991 24" x 24" x 60" MER3992 • The base metal is zinc plated & then powder coated for a longer life and less rust/corrosion • Lockable T-Handles • Dust cap on door locks • Single piece main structure for a stronger box, less welds • “Automotive” style weather stripping MER253 Diamond Plate Door with No Drill Mounting Kit 22" x 9" x 24" • Easy installation using clamps – no drilling of the frame • Mounting Kit Included • Lockable latching system ALUMINUM BETWEEN-THE-FRAME TOOL BOX MOUNTING BRACKETS FOR ALUMINUM TOOL BOXES & BAWER BOXES
MER453 Diamond Plate Finish w/ Step 23-1/2" x 28-1/2" x 12" MER473 Diamond Plate Finish w/ Step 23-1/2" x 28-1/2" x 24" MER452 Smooth Finish w/ Step 23-1/2" x 28-1/2" x 12" MER462 Smooth Finish w/ Step 23-1/2" x 28-1/2" x 18" MER472 Smooth Finish w/ Step 23-1/2" x 28-1/2" x 24" MER482* Smooth Finish w/ Step 23-1/2" x 28-1/2" x 36" MER450 Smooth Finish 22" x 21" x 12" MER470 Smooth Finish 22" x 21" x 24" Dyna-Deck Top Mount MER432 18-1/2" Long x 33-1/4" Wide MER433 28" Long x 33-1/4" Wide MER434 37-1/2" Long x 33-1/4" Wide MER233 24" Chain Carrier w/ Lid, 300 lbs. Capacity MER384 18" Chain Carrier w/ Lid, 300 lbs. Capacity MER119 “No-Drill” Mounting Kit (Fits 233 & 384) MER3840 18" Chain Carrier No Lid • Extruded door frame with full perimeter automotive door seal for a water resistant closure • Mounting Kit welded inside of all Saddle Boxes (Bolts Not Included) • Heavy Duty design on all storage boxes for a longer life • Aluminum for low weight, yet high strength • Expandable to fit your needs • Non-Skid ribbed deck surface • Self Draining • Safe, meets D.O.T. Regulations for a walk area! • Variable Mounting Points • Low Installation Time • Mounting Kit Included Easy Slide Together Panels Dyna-Deck Flush Mount MER442 18-1/2" Long X 30-1/4" Wide MER443 28" Long X 30-1/4" Wide MER445 46-3/4" Long x 33-1/4" Wide • Lower Step “foot stop, no shin bruises” • Sturdy bolt on design, light but strong • Bright Aluminum throughout MER182 Frame Step 12" Wide • Strong heavy duty design, body built of high strength, zinc plated steel • Sturdy frame mount design- light but strong (Weighs only 25 lbs. empty) • Locking diamond plate aluminum cover- bright and strong • Only 8" wide, space saving mount * MER117 or MER118 Mounting Kit Required. FOLDING HANDLE MER3519 - LH • Option to add to your saddle box • Provides 3-point touch access when stepping onto box to get on truck frame • Folding handles fold down for better storage when not in use Side Pack Box MER491 15 3/4 x 23 x 24 without steps MER490 18 x 28 7/8 x 30 1/8 with steps Stack-Pack Box MER3504 4 Battery Box w/ Top Deck Plate 25 x 20 x 16 Frame-Pack Box MER258 4 Battery In-Frame Battery Box* 12 x 23 x 27 3/4 *With Hinged Lid. Includes Mounting and Battery Hold Down Kits • Made from a strong, yet lightweight aluminum alloy, for long life and weight savings • Side frame units can mount using a frame drill bracket or a No-Drill kit that does not need to drill the frame • In-Frame box does not require any frame drilling to mount • All boxes come with or have an optional battery hold down kit • Battery boxes will hold two, four or six group 31 batteries MIDWESTWHEEL.COM MEMBER KANSAS CITY 5801 E. Front St. Main .... (816) 471-1552 Parts.... (800) 821-7402 JOPLIN 2424 Stephens Blvd. Main .... (417) 717-6022 Parts.... (866) 318-9111 SPRINGFIELD 812 Lillian Dr. ∙ Strafford, MO Main .... (417) 429-2476 Parts.... (800) 785-3705 SIOUX CITY 1819 4th St. Main .... (712) 252-7969 Parts.... (800) 943-3534 CEDAR RAPIDS 200 50th Ave. S.W. Main .... (319) 365-4453 Parts.... (800) 332-5435 DES MOINES 1436 E. Ovid Ave. Main .... (515) 265-1491 Parts.... (800) 888-0248 CLEAR LAKE 840 Hwy. 18 W. Main .... (641) 357-7101 Parts.... (800) 397-5630 DAVENPORT 8502 Northwest Blvd. Main .... (563) 322-2671 Parts.... (800) 553-1886 OMAHA 5822 F St. Main .... (531) 239-3050 Parts.... (800) 322-8757 NEBRASKA IOWA MISSOURI April 26, 2023 (09Merritt Products) ALUMINUM SADDLE BOXES ALUMINUM DECK COVER BATTERY BOXES FRAME STEP TIRE CHAIN CARRIER - FRAME MOUNT Top Mount Flush Mount
